INJECTION MOLD P2 2 Types of Dies
Within the plastics industry, the term die is most often applied to the processes of extrusion (see EXTRUSION). Extrusion dies may be categorized by the type of product being produced (e.g., film, sheet, profile, or coextrusion), but they all have some common features as described below.
FIGURE PP.1 Three basic types of molds.
(a) single-cavity; (b) dedicated multiple-cavity; (c) family multiple-cavity.
- Steel. The extrusion process being continuous, both erosion and corrosion are significant factors. Hence the dies must be made of a high-quality tool steel, hardened so that the areas that contact the plastic material do not erode. Additionally, many dies have a dense, hard chrome plating in the area where plastic melt contacts the die.
- Heaters. Extrusion dies are to be heated in order to maintain a melt flow condition for the plastic material. Most of the heaters are cartridge-type elements that slip fit into the die at particular locations. In addition to the heaters, the dies have to accommodate temperature sensors, such as thermocouples.
- Melt Pressure. Many sophisticated dies are equipped with sensors that monitor melt pressure. This allows the processor to better monitor ad control the process.
- Parting Line. Large extrusion dies must be able to separate at the melt flow line for easier fabrication and maintenance. Smaller extrusion dies may not have a parting area, because they can be constructed in one piece.
- Die Swell Compensation. The polymer melt swells when it exits the die, as explained previously. This die swell is a function of the type of plastic material, the melt temperature, the melt pressure, and the die configuration. The die must be compensated for die swell so that the extruded part has the corrected shape and dimensions. Molds and dies for different fabrication processes will be described later in more detail when the processes are discussed.
|
